CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 191
Analogue Comparator 3, Polar
[6135]
Function is identical to analogue comparator 1,
Polar [6115].
Communication information
CA4 Setup [614]
Analogue comparators 4, parameter group.
Analogue Comparator 4, Value
[6141]
Function is identical to analogue comparator 1,
value [6111].
Communication information
Analogue Comparator 4, Level High
[6142]
Function is identical to analogue comparator 1 level high
[6112].
Communication information
Analogue Comparator 4,
Level Low [6143]
Function is identical to analogue comparator 1, level low
[6113].
Communication information
6135 CA3 Polar
Default: Unipolar
Unipolar 0 Absolute value of [6111] used
Bipolar 1 Signed value of [6111] used
Modbus Instance no/DeviceNet no: 43488
Profibus slot/index 170/137
EtherCAT and CANopen index (hex) 4da0
Profinet IO index 19872
Fieldbus format UInt
Modbus format UInt
6141 CA4 Value
Default: Process Error
Selections: Same as in menu [6111]
Modbus Instance no/DeviceNet no: 43474
Profibus slot/index 170/123
EtherCAT and CANopen index (hex) 4d92
Profinet IO index 19858
Fieldbus format UInt
Modbus format UInt
6142 CA4 Level HI
Default: 100rpm
Range: Enter a value for the high level.
Modbus Instance no/DeviceNet no: 43475
Profibus slot/index 170/124
EtherCAT and CANopen index (hex) 4d93
Profinet IO index 19859
Fieldbus format
Long
1=1 W, 0.1 A, 0.1 V,
0.1 Hz, 0.1
°C, 1 kWh,
1H, 1%, 1 rpm or 0.001
via process value
Modbus format EInt
6143 CA4 Level LO
Default: -100 rpm
Range: Enter a value for the low level.
Modbus Instance no/DeviceNet no: 43476
Profibus slot/index 170/125
EtherCAT and CANopen index (hex) 4d94
Profinet IO index 19860
Fieldbus format
Long,
1=1 W, 0.1 A, 0.1 V,
0.1 Hz, 0.1
°C, 1 kWh,
1H, 1%, 1 rpm or 0.001
via process value
Modbus format EInt
