CG Emotron VFX Series User Manual

190 CG Drives & Automation, 01-5326-01r5
CA3 Setup [613]
Analogue comparators 3, parameter group.
Analogue Comparator 3, Value
[6131]
Function is identical to analogue comparator 1,
value [6111].
Communication information
Analogue Comparator 3,
Level High [6132]
Function is identical to analogue comparator 1,
level high [6112].
Communication information
Analogue Comparator 3,
Level Low [6133]
Function is identical to analogue comparator 1,
level low [6113].
Communication information
Analogue Comparator, 3 Type
[6134]
Function is identical to analogue comparator 1, level Type
[6114].
Communication information
6131 CA3 Value
Default: Process Value
Selections: Same as in menu [6111]
Modbus Instance no/DeviceNet no: 43471
Profibus slot/index 170/120
EtherCAT and CANopen index (hex) 4d8f
Profinet IO index 19855
Fieldbus format UInt
Modbus format UInt
6132 CA3 Level HI
Default: 300rpm
Range: Enter a value for the high level.
Modbus Instance no/DeviceNet no: 43472
Profibus slot/index 170/121
EtherCAT and CANopen index (hex) 4d90
Profinet IO index 19856
Fieldbus format
Long
1=1 W, 0.1 A, 0.1 V,
0.1 Hz, 0.1
°C, 1 kWh,
1H, 1%, 1 rpm or 0.001
via process value
Modbus format EInt
6133 CA3 Level LO
Default: 200 rpm
Range: Enter a value for the low level.
Modbus Instance no/DeviceNet no: 43473
Profibus slot/index 170/122
EtherCAT and CANopen index (hex) 4d91
Profinet IO index 19857
Fieldbus format
Long,
1=1 W, 0.1 A, 0.1 V,
0.1 Hz, 0.1
°C, 1 kWh,
1H, 1%, 1 rpm or 0.001
via process value
Modbus format EInt
6134 CA3 Type
Default: Hysteresis
Hysteresis 0 Hysteresis type comparator
Window 1 Window type comparator
Modbus Instance no/DeviceNet no: 43483
Profibus slot/index 170/132
EtherCAT and CANopen index (hex) 4d9b
Profinet IO index 19867
Fieldbus format UInt
Modbus format UInt
