CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 189
Analogue Comparator 2,
Level High [6122]
Function is identical to analogue comparator 1,
level high [6112].
Communication information
Analogue Comparator 2,
Level Low [6123]
Function is identical to analogue comparator 1,
level low [6113].
Communication information
Analogue Comparator 2, Type
[6124]
Function is identical to analogue comparator 1,
Type [6114].
Communication information
Analogue Comparator 2, Polar
[6125]
Function is identical to analogue comparator 1,
Polar [6115].
Communication information
6122 CA2 Level HI
Default: 20%
Range: Enter a value for the high level.
Modbus Instance no/DeviceNet no: 43405
Profibus slot/index 170/54
EtherCAT and CANopen index (hex) 4d4d
Profinet IO index 19789
Fieldbus format
Long
1=1 W, 0.1 A, 0.1 V,
0.1 Hz, 0.1
°C, 1 kWh,
1H, 1%, 1 rpm or 0.001
via process value
Modbus format EInt
6123 CA2 Level LO
Default: 10%
Range: Enter a value for the low level.
Modbus Instance no/DeviceNet no: 43406
Profibus slot/index 170/55
EtherCAT and CANopen index (hex) 4d4e
Profinet IO index 19790
Fieldbus format
Long,
1=1 W, 0.1 A, 0.1 V,
0.1 Hz, 0.1
°C, 1 kWh,
1H, 1%, 1 rpm or 0.001
via process value
Modbus format EInt
6124 CA2 Type
Default: Hysteresis
Hysteresis 0 Hysteresis type comparator
Window 1 Window type comparator
Modbus Instance no/DeviceNet no: 43482
Profibus slot/index 170/131
EtherCAT and CANopen index (hex) 4d9a
Profinet IO index 19866
Fieldbus format UInt
Modbus format UInt
6125 CA2 Polar
Default: Unipolar
Unipolar 0 Absolute value of [6111] used
Bipolar 1 Signed value of [6111] used
Modbus Instance no/DeviceNet no: 43487
Profibus slot/index 170/136
EtherCAT and CANopen index (hex) 4d9f
Profinet IO index 19871
Fieldbus format UInt
Modbus format UInt
