CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 205
Frequency [718]
Displays the actual output frequency.
Communication information
DC Link Voltage [719]
Displays the actual DC link voltage.
Communication information
Heatsink Temperature [71A]
Displays the actual heatsink temperature, measured. The
signal is generated by a sensor in the IGBT module.
Communication information
PT100_1_2_3 Temp [71B]
Displays the actual PT100 temperature, for PT100 board 1.
Communication information
PT100_4_5_6 Temp[71C]
Displays the actual PT100 temperature, for PT100 board 2.
Communication information
718 Frequency
Unit: Hz
Resolution: 0.1 Hz
Modbus Instance no/DeviceNet no: 31009
Profibus slot/index 121/153
EtherCAT and CANopen index (hex) 23f1
Profinet IO index 1009
Fieldbus format Long, 1=0.1 Hz
Modbus format EInt
719 DC Voltage
Unit: V
Resolution: 0.1 V
Modbus Instance no/DeviceNet no: 31010
Profibus slot/index 121/154
EtherCAT and CANopen index (hex) 23f2
Profinet IO index 1010
Fieldbus format Long, 1=0.1 V
Modbus format EInt
71A Heatsink Tmp
Unit: °C
Resolution: 0.1°C
Modbus Instance no/DeviceNet no: 31011
Profibus slot/index 121/155
EtherCAT and CANopen index (hex) 23f3
Profinet IO index 1011
Fieldbus format Long, 1=0.1
°C
Modbus format EInt
71B PT100 1,2,3
Unit: °C
Resolution: 1°C
Modbus Instance no/DeviceNet no: 31012, 31013, 31014
Profibus slot/index
121/156
121/157
121/158
EtherCAT and CANopen index (hex) 23f4, 23f5, 23f6
Profinet IO index 1012, 1013, 1014
Fieldbus format Long, 1=1 °C
Modbus format EInt
71C PT100 4,5,6
Unit: °C
Resolution: 1°C
Modbus Instance no/DeviceNet no: 31097, 31098, 31099
Profibus slot/index
121/241
121/242
121/243
EtherCAT and CANopen index (hex) 2449, 244a, 244b
Profinet IO index 1097, 1098, 1099
Fieldbus format Long, 1=1 °C
Modbus format EInt
