CipherLab 2564 User Manual

201
Update
The scanner allows advanced data editing by applying user-configured editing formats.
The whole processed data can be divided into fields by user-specified rules. These fields
together with the user-configurable additional fields consist of the data actually sent to
the host computer.
To apply any editing format, the maximum output data length of a barcode is 7 KB after
configuration. When the data length exceeds 7 KB, editing format will not take effect.
[Prefix Code]
[Code ID]
[Length Code]
[Data]
[Suffix Code]
Additional
Field(s)
None
by default
None
by default
None
by default
Barcode itself
0x0d
by default
IN THIS CHAPTER
6.1 Activating Editing Formats ......................................... 202
6.2 How to Configure Editing Formats ............................... 204
6.3 Configuring Format — Define Data Criteria ................... 207
6.4 Configuring Format — Define Data Field ....................... 218
6.5 Configuring Format — Define Transmission Sequence .... 226
6.6 Programming Examples ............................................. 229
Chapter 6
APPLYING FORMATS FOR DATA EDITING
