218
End Programming Format
2564 Barcode Scanner User Guide
6.4 CONFIGURING FORMAT — DEFINE DATA FIELD
6.4.1 START POSITION
Data can be divided into fields in one of the following direction –
from head (F1) to tail (F5)
from tail (F1) to head (F5)
6.4.2 FIELD ADJUSTMENT
Apply equal length to all fields, if necessary. If data is found longer than specified, it will
be truncated automatically. When data is found shorter, it will add “Space” (0x20) to
field.
Set length to adjust
fields… (*0)
1) Read the barcode above to adjust field by length.
2) Read the “Decimal Value” barcode on page 251 for the desired field length.
3) Read the “Validate” barcode on the same page to complete this setting.
To Next Page
