3-14

Cisco Wireless LAN Controller Configuration Guide

OL-17037-01

Chapter 3 Configuring Ports and Interfaces

Configuring the Management, AP-Manager, Virtual, and Service-Port Interfaces

Using the CLI to Configure the AP-Manager Interface

Follow these steps to display and configure the AP-manager interface parameters using the CLI.

Step 1 Enter show interface summary to view the current interfaces.

Note If the system is operating in Layer 2 mode, the AP-manager interface is not listed.

Step 2 Enter show interface detailed ap-manager to view the current AP-manager interface settings.

Step 3 Enter config wlan disable wlan-number to disable each WLAN that uses the AP-manager interface for

distribution system communication.

Step 4 Enter these commands to define the AP-manager interface:

• config interface address ap-manager ip-addr ip-netmask gateway

• config interface vlan ap-manager {vlan-id | 0}

Note Enter 0 for an untagged VLAN or a non-zero value for a tagged VLAN. Cisco recommends

using tagged VLANs for the AP-manager interface.

• config interface port ap-manager physical-ds-port-number

• config interface dhcp ap-manager ip-address-of-primary-dhcp-server

[ip-address-of-secondary-dhcp-server]

• config interface acl ap-manager access-control-list-name

Note See Chapter 5 for more information on ACLs.

Step 5 Enter save config to save your changes.

Step 6 Enter show interface detailed ap-manager to verify that your changes have been saved.

Using the CLI to Configure the Virtual Interface

Follow these steps to display and configure the virtual interface parameters using the CLI.

Step 1 Enter show interface detailed virtual to view the current virtual interface settings.

Step 2 Enter config wlan disable wlan-number to disable each WLAN that uses the virtual interface for

distribution system communication.
