Cisco 2100 Series Configuration Guide

5-17
Cisco Wireless LAN Controller Configuration Guide
OL-17037-01
Chapter 5 Configuring Security Solutions
Configuring RADIUS
RADIUS Accounting Attributes
Table 5-6 identifies the RADIUS accounting attributes for accounting requests sent from a controller to
the RADIUS server. Table 5-7 lists the different values for the Accounting-Status-Type attribute (40).
Table 5-5 Authentication Attributes Honored in Access-Accept Packets (Airespace)
Attribute ID Description
1 VAP-ID
2QoS-Level
3DSCP
4 8021P-Type
5 VLAN-Interface-Name
6ACL-Name
7 Data-Bandwidth-Average-Contract
8 Real-Time-Bandwidth-Average-Contract
9 Data-Bandwidth-Burst-Contract
10 Real-Time-Bandwidth-Burst-Contract
11 Guest-Role-Name
Table 5-6 Accounting Attributes for Accounting Requests
Attribute ID Description
1User-Name
4 NAS-IP-Address
5NAS-Port
8 Framed-IP-Address
25 Class
30 Called-Station-ID (MAC address)
31 Calling-Station-ID (MAC address)
32 NAS-Identifier
40 Accounting-Status-Type
41 Accounting-Delay-Time (Stop and interim messages only)
42 Accounting-Input-Octets (Stop and interim messages only)
43 Accounting-Output-Octets (Stop and interim messages only)
44 Accounting-Session-ID
45 Accounting-Authentic
46 Accounting-Session-Time (Stop and interim messages only)
47 Accounting-Input-Packets (Stop and interim messages only)
48 Accounting-Output-Packets (Stop and interim messages only)
49 Accounting-Terminate-Cause (Stop messages only)

Cisco 2100 Series Specifications

General

Power over Ethernet (PoE)	No
Form Factor	Desktop
Encryption	AES, TKIP
Maximum Access Points	6
Security	WPA, WPA2, 802.1X
Dimensions	1.75 x 8.0 x 8.5 in. (4.4 x 20.3 x 21.6 cm)
