34-53
Cisco ME 3800X and 3600X Switch Software Configuration Guide
OL-23400-01
Chapter 34 Configuring MPLS, MPLS VPN, MPLS OAM, and EoMPLS
Configuring MPLS OAM and IP SLAs MPLS
Step 20
auto ip sla mpls-lsp-monitor
reaction-configuration operation-number react
monitored-element [action-type option]
[threshold-type {consecutive [occurrences] |
immediate | never}]
(Optional) Configure other LSP Health Monitor actions:
• operation-number—Enter the operation number.
• react monitored-element—Specify the element to be
monitored for violations. For example, enter
connectionLoss to configure a reaction to a 1-way
connection loss for the operation.
• (Optional) action-type option—Specify the action to take
when the threshold event occurs. For example, enter none
for no action or trapOnly to send an SMNP logging trap.
• (Optional) threshold-type—Specify when the action-type
occurs. These are the options:
–
consecutive [occurrences]—When reaction conditions
are met consecutively for a specified number of times.
The valid range is from 1 to 16; the default is 5.
–
(Optional) threshold-type immediate—When the
reaction conditions are met.
–
(Optional) threshold-type never—Never. This is the
default threshold type.
Step 21
auto ip sla mpls-lsp-monitor schedule
operation-number schedule-period seconds
[frequency seconds] [start-time {hh:mm {:ss}
[month day | day month] | pending | now | after
hh:mm:ss}]
Schedule time parameters for the LSP Health Monitor.
• operation number—Enter the operation number.
• schedule-period seconds—Enter the schedule period in
seconds. The range is 1 to 604800 seconds.
• (Optional) frequency seconds—Enter the frequency for
LSP monitoring in seconds. The range is 1 to 604800
seconds.
• (Optional) start-time—Enter the time for the operation to
begin collecting information:
–
To start at a specific time, enter the hour, minute,
second (in 24-hour notation) and day of the month. If
no month is entered, the default is the current month.
–
Enter pending to select no information being collected
until a start time is selected.
–
Enter now to start the operation immediately.
–
Enter after hh:mm:ss to indicate that the operation
should start after the entered time has elapsed.
Step 22
auto ip sla mpls-lsp-monitor reset (Optional) Reset LDP monitor group statistics.
Step 23
end Return to privileged EXEC mode.
Step 24
show ip sla mpls-lsp-monitor configuration
[operation-number]
Show the configured LSP monitoring operations.
Step 25
copy running-config startup-config (Optional) Save your entries in the configuration file.
Step 26
show ip sla mpls-lsp-monitor summary Display a summary of IP SLAs LSP MPLS status.
Command Purpose
