Cisco ASA Series User Manual

1-14
Cisco ASA Series CLI Configuration Guide
Chapter 1 Configuring Cisco Intercompany Media Engine Proxy
Configuring Cisco Intercompany Media Engine Proxy
Step 4
hostname(config)# object service name
Examples:
hostname(config)# object service tcp_5070
hostname(config)# object service tcp_5071
Creates a service object for the outside Cisco
Intercompany Media Engine port.
Step 5
hostname(config-service-object)# tcp source eq port
Examples:
hostname(config-service-object)# tcp source eq 5070
hostname(config-service-object)# tcp source eq 5071
Specifies the port number.
Step 6
hostname(config-service-object)# exit
Exits from the objects configuration mode.
Step 7
hostname(config)# object network name
Examples:
hostname(config)# object network
ucm-real-192.168.10.30
hostname(config)# object network
ucm-real-192.168.10.31
Configures a network object to represent the real IP
address of Cisco UCM.
Step 8
hostname(config-network-object)# host ip_address
Examples:
hostname(config-network-object)# host 192.168.10.30
hostname(config-network-object)# host 192.168.10.31
Specifies the real IP address of the Cisco UCM host
for the network object.
Step 9
hostname(config-network-object)# exit
Exits from the objects configuration mode.
Step 10
hostname(config)# object service name
Examples:
hostname(config)# object service tcp_5570
hostname(config)# object service tcp_5571
Creates a service objects for Cisco UCM SIP port.
Step 11
hostname(config-service-object)# tcp source eq port
Example:
hostname(config-service-object)# tcp source eq 5570
hostname(config-service-object)# tcp source eq 5571
Specifies the port number.
Step 12
hostname(config-service-object)# exit
Exits from the objects configuration mode.
Step 13
hostname(config)# nat (inside,outside) source static
real_obj mapped_obj service real_port mapped_port
Examples:
hostname(config)# nat (inside,outside) source static
ucm-real-192.168.10.30 ucm-pat-209.165.200.228
service tcp_5070 tcp_5570
hostname(config)# nat (inside,outside) source static
ucm-real-192.168.10.31 ucm-pat-128.106.254.5 service
tcp_5071 tcp_5571
Creates a static mapping for Cisco UCM.
Where real_obj is the name that you created in
Step 1 in this task.
Where mapped_obj is the name that you created in
Step 7 in this task.
Where real_port is the name that you created in
Step 4 in this task.
Where mapped_obj is the name that you created in
Step 10 in this task.
Command Purpose

Cisco ASA Series Specifications

General

Model	ASA 5505
Interfaces	Varies by model (Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet, etc.)
High Availability	Active/Standby or Active/Active (varies by model)
Power Supply	Varies by model
Form Factor	Varies by model
Operating System	Cisco ASA Software
IPsec VPN	Supported
SSL VPN	Supported
IPS Throughput	Varies by model
