Cisco ASR 5000 Series User Manual

ASR 5000 Hardware Platform Overview
▀ ASR 5000 Line Cards
▄ Cisco ASR 5000 Series Product Overview
OL-22938-02
Module Type
Card
Identification
Interface Type
Cable Specifications
10GBase-
SR
Ethernet 10G SR
Fiber, LC duplex female
connector
Fiber Type: Multi-mode fiber (MMF), 850 nm
wavelength
Core Size (microns)/Range:
62.5/902.23 feet (275 meters)
50/1640.42 feet (500 meters)
62.5um/33m (OM1)
50um 500MHz-km/82m (OM2)
50um 2000MHz-km/300m (OM3)
Minimum Tx Power: -7.3 dBm
Rx Sensitivity: -11.1 dBm
10GBase-
LR
Ethernet 10G LR
Fiber, LC duplex female
connector
Fiber Type: Single-mode fiber (SMF), 1310 nm
wavelength
Core Size (microns)/Range: 9/32808.4 feet (10
Kilometers)
Minimum Tx Power: -11.0 dBm
Rx Sensitivity: -19 dBm
Important: Class 1 Laser Compliance Notice This product has been tested and found to comply with the limits
for Class 1 laser devices for IEC825, EN60825, and 21CFR1040 specifications.
WARNING: Only trained and qualified personnel should install, replace, or service this equipment. Invisible laser
radiation may be emitted from the aperture of the port when no cable is connected. Avoid exposure to laser radiation
and do not stare into open apertures. BE SURE TO KEEP COVER ON INTERFACE WHEN NOT IN USE.
Important: Disposal of this product should be performed in accordance with all national laws and regulations.
The following shows the front panel of the XGLC, identifying its interfaces and major components:

Cisco ASR 5000 Series Specifications

General

Brand	Cisco
Model	ASR 5000 Series
Category	Network Router
Language	English
