ASR 5000 Hardware Platform Overview

ASR 5000 Line Cards ▀

Cisco ASR 5000 Series Product Overview ▄

OL-22938-02

Figure 23. 10 Gigabit Ethernet Line Card (XGLC)

Ethernet

10G

Table 19. 10 Gigabit Ethernet Line Card (GLC) Callout Definitions

Number

Description

Card Ejector Levers—Use to insert/remove card to/from chassis.

Interlock Switch—When pulled downward, the interlock switch notifies system to safely power down card prior

to removal.

Card Level Status LEDs—Show the status of the card. (See Applying Power and Verifying Installation for definitions)
