Technical Specifications

Interface Specifications ▀

Cisco ASR 5000 Series Product Overview ▄

OL-22938-02

Figure 223. CO Alarms Cable Assembly

Table 111. CO Alarms Cable Pinout

CO Alarms Interface Pin

Number

Cable Connector Pin

Number

Cable Wire

Color

Cable Terminal Block Position

Number

Signal

Black

Major Alarm - Normally

closed

Orange

Major Alarm - Common

Red

Major Alarm - Normally

open

Brown

Minor Alarm - Normally

closed

Yellow

Minor Alarm - Common

Green

Minor Alarm - Normally

open

Blue

Critical Alarm - Normally

closed

Violet

Critical Alarm - Common

Gray

Critical Alarm - Normally

open

Not

Applicable

Not Applicable
