Cisco Catalyst 2950 Hardware Installation Guide

1-9
Catalyst 2950 Desktop Switch Hardware Installation Guide
78-11157-05
Chapter 1 Quick Installation
Entering the Initial Configuration Information
interface GigabitEthernet0/2
!
end
Step 10 These choices appear:
[0] Go to the IOS command prompt without saving this config.
[1] Return back to the setup without saving this config.
[2] Save this configuration to nvram and exit.
If you want to save the configuration and use it the next time the switch reboots,
save it in nonvolatile RAM (NVRAM) by selecting option 2.
Enter your selection [2]:2
Make your selection, and press Return.
After you complete the setup program, the switch can run the default
configuration that you created. If you want to change this configuration or want
to perform other management tasks, use one of these tools:
• CLI
• CMS from your browser
To use the CLI, enter commands at the Switch> prompt through the console port
by using a terminal program or through the network by using Telnet. For
configuration information, refer to the switch software configuration guide or the
switch command reference.
To use the CMS, go to “Accessing the Switch from Your Browser” section on
page 1-11.

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
