Chapter 3 Installation
Installing the Switch in a Rack
Figure 3-9 Attaching Brackets on the Catalyst 2950G-24-EI-DC or 2950ST-24 LRE 997 Switch in
a 23-Inch Telco Rack
Figure 3-10 Attaching Brackets on the Switch in a 24-Inch Rack (Front Panel
Forward)
CONSOLE
65675
Number-8
Phillips
truss-head
screws
SYST RPS
DUPLX
MODE
SPEED
UTIL
S TAT
1X
2X
11X
12X
1
2
3
4
5
6
7
8
9
10
11
12
65666
Number-8
Phillips
truss-head
screws
