For USA and Canada, this certification is CSA Class 1, Division 2. For Europe (EU), it is ATEX or IEC
Class 1, Zone 2.
Note
Cisco has Hazardous Certified SKUs for USA and EU: AIR-LAP1522HZ-x-K9, AIR-LAP1524HZ-x-K9,
and AIR-LAP1552H-x-K9. These SKUs are modified, as per the certification requirements. The hazardous
locations certificate requires that all electrical power cables be run through conduit piping to protect against
accidental damage to the electrical wiring that could cause a spark and possible explosion. Access points for
hazardous locations contain an internal electrical mounting connect that receives discrete wires from a conduit
interface coupler entering from the side of the housing. After the electrical wiring is installed, a cover housing
is installed over the electrical connector to prevent exposure to the electrical wiring. The outside of the housing
has a hazardous location certification label (CSA, ATEX, or IEC) that identifies the type of certifications and
environments that the equipment is approved for operation.
Power entry module for CSA (USA and Canada) is Power Entry Module, Groups A, B, C, and D with
T5v(120° C) temp code. Power Entry Module for ATEX (EU) is Power entry module Groups IIC, IIB,
IIA with T5 (120° C) temp code.
Note
Hazardous Certification (Div 1 > Div 2 and Zone 1 > Zone 2)
Class 1, Division 1/Zone 1 is for environments with full-time ignitable concentrations of flammable gases,
vapors, or liquids. To meet the requirements of the Div 1 > Div 2 and Zone 1 > Zone 2 locations, we recommend
a TerraWave Solutions CSA certified protective Wi-Fi enclosure (see Table 12: TerraWave Enclosures, on
page 38).
Table 12: TerraWave Enclosures
DescriptionEnclosure Part NoAccess Points
18 x12 x8 Protective Wi-Fi Enclosure that
includes the Cisco 1242 Access Point
Example: TerraWave
XEP1242 for 1240 series.
Indoor Mesh Access Points
(Cisco Aironet 1040, 1130,
1140, 1240, 1250, 1260,
3500e, and 3500i series
access points)
18 x 12 x8 Protective Wi-Fi Enclosure that
includes the Cisco 1522 Access Point
Example: TerraWave Part
Number: XEP1522
Outdoor Mesh Access
Points (1522, 1524, 1552)
For more information about the TerraWave enclosures, see http://www.tessco.com/yts/partner/manufacturer_list/
vendors/terrawave/pdf/terrawavehazardouesenclosuresjan08.pdf
Table 13: Hardware Features at a Glance, on page 39 lists the hardware features across different AP1500
models at a glance.
Cisco Mesh Access Points, Design and Deployment Guide, Release 7.3
38 OL-27593-01
