Table 23: Lowest of AP to Client and Half of AP to AP Backhaul Distance
Half of AP to AP backhaul Distance in
5 GHz
AP to Client 2.4 GHzAP Type (-A Domain)
415 meters (1360 feet)250 meters (800 feet)1552 C/I
560 meters (1840 feet)300 meters (1000 feet)1552 E/H
For the AP to the AP distance, you can take double the AP to the client distance (see Table 24:
Recommendations for Cell Radius, on page 79).
Table 24: Recommendations for Cell Radius
AP to APAP to ClientAP Type (-A Domain)
500 meters (1600 feet)250 meters (800 feet)1552 C/I
600 meters (2000 feet)300 meters (1000 feet)1552 E/H
Cisco Mesh Access Points, Design and Deployment Guide, Release 7.3
OL-27593-01 79
Site Preparation and Planning
Cell Planning and Distance
