ATA Routing Field Reference
LAN Status page
Cisco Small Business ATA Administration Guide 106
A
VLAN Settings section
LAN Status page
You can use the LAN Status page to view the LAN settings. This page includes the
following sections:
Networking Service section, on page 106
LAN Networking Settings section, on page 107
Static DHCP Lease Settings section, on page 107
Networking Service section
Maximum Uplink
Speed
The maximum bandwidth for LAN to WAN throughput.
The default is 128 kbps.
Enable VLAN Allows (yes) or prevents (no) VLAN access.
NOTE: Choose yes if your ATA device is connected to
a switch that uses VLAN tagging.
VLAN ID The VLAN tag for the VLAN to which the ATA device is
assigned.
Networking Service NATthe unit acts as a router and provides IP
addresses to PCs attached to the LAN port.
BridgeThe unit acts as a switch, a passthrough, and
does not give IP addresses.
