Cisco SPA2102 - Distinctive Ring Settings Section

ATA Voice Field Reference
User page
Cisco Small Business ATA Administration Guide 220
B
Distinctive Ring Settings section
Caller number patterns are matched from Ring 1 to Ring 8. The first match (not the
closest match) will be used for alerting the subscriber.
Accept Media
Loopback Request
Controls how to handle incoming requests for loopback
operation. Choices are: Never, Automatic, and Manual,
where:
 nevernever accepts loopback calls; reply 486 to the caller
 automaticautomatically accepts the call without ringing
 manual rings the phone first, and the call must be picked
up manually before loopback starts.
The default is Automatic.
Media Loopback
Mode
The loopback mode to assume locally when making call to
request media loopback. Choices are: Source and Mirror.
Default is Source.
Note that if the ATA device answers the call, the mode is
determined by the caller.
Media Loopback
Type
The loopback type to use when making call to request
media loopback operation. Choices are Media and Packet.
Default is Media.
Note that if the ATA device answers the call, then the
loopback type is determined by the caller (the ATA device
always picks the first loopback type in the offer if it
contains multiple types.)
Ring1 - 9 Caller Caller number pattern to play Distinctive Ring/CWT 1, 2, 3,
4, 5, 6, 7, 8, or 9.
The default is blank.
