Introducing Cisco Small Business Analog Telephone Adapters
ATA Connectivity Requirements
Cisco Small Business ATA Administration Guide 20
1
SPA8800 Connectivity
As shown in the following figure, the SPA8800 has four voice modules that each
provide 1 FXS port and 1 FXO port.
By default, the device on the LAN port is assigned the network address
192.168.0.0 with a subnet mask of 255.255.255.0. If there is a network address
conflict with a device on the Ethernet port, the network address of the device on
the LAN port is automatically changed to 192.168.1.0.
IP
IP
