Configuring Voice Services
Managing Caller ID Service
Cisco Small Business ATA Administration Guide 53
4
Managing Caller ID Service
The choice of caller ID (CID) method is dependent on your area/region. To
configure CID, use the following parameters:
Parameter Tab Description and Value
Caller ID
Method
Regional The following choices are available:
 Bellcore (N.Amer,China)CID, CIDCW, and VMWI.
FSK sent after first ring (same as ETSI FSK sent after
first ring) (no polarity reversal or DTAS).
 DTMF (Finland, Sweden)CID only. DTMF sent after
polarity reversal (and no DTAS) and before first ring.
 DTMF (Denmark)CID only. DTMF sentbefore first
ring with no polarity reversal and no DTAS.
 ETSI DTMFCID only. DTMF sent after DTAS (and no
polarity reversal) and before first ring.
 ETSI DTMF With PRCID only. DTMF sent after
polarity reversal and DTAS and before first ring.
 ETSI DTMF After RingCID only. DTMF sent after
first ring (no polarity reversal or DTAS).
 ETSI FSKCID, CIDCW, and VMWI. FSK sent after
DTAS (but no polarity reversal) and before first ring.
Waits for ACK from CPE after DTAS for CIDCW.
 ETSI FSK With PR (UK)CID, CIDCW, and VMWI.
FSK is sent after polarity reversal and DTAS and
before first ring. Waits for ACK from CPE after DTAS for
CIDCW. Polarity reversal is applied only if equipment
is on hook.
 DTMF (Denmark) With PRCID only. DTMF sent after
polarity reversal (and no DTAS) and before first ring.
The default is Bellcore(N.Amer, China).
Caller ID
FSK
Standard
Regional
The ATA device supports bell 202 and v.23
standards for caller ID generation. Select the FSK
standard you want to use, bell 202 or v.23.
The default is bell 202.
This field is not found in the PAP2T.
