Cisco SPA2102 User Manual

ATA Voice Field Reference
PSTN Line page (SPA3102)
Cisco Small Business ATA Administration Guide 209
B
Ring Settings section
FXO (PSTN) Timer Values (sec) section
Default Ring 1-8, Follow Line Cfg
VoIP Answer Delay Delay in seconds before auto-answering inbound VoIP calls
for the FXO account. The range is 0-255.
The default is 3.
PSTN Answer
Delay
Delay in seconds before auto-answering inbound PSTN
calls after the PSTN starts ringing. The range is 0-255.
The default is 16.
VoIP PIN Digit
Timeout
Timeout to wait for the 1
st
or subsequent PIN digits from a
VoIP caller. The range is 0-255.
The default is 10.
PSTN PIN Digit
Timeout
Timeout to wait for the 1
st
or subsequent PIN digits from a
PSTN caller. The range is 0-255.
The default is 10.
VoIP DLG Refresh
Intvl
Interval between (SIP) Dialog refresh messages sent by
the SPA to detect if the VoIP call-leg is still up. If value is set
to 0, SPA will not send refresh messages and VoIP call-leg
status is not checked by the SPA. The refresh message is a
SIP ReINVITE and the VoIP peer must response with a 2xx
response. If VoIP peer does not reply or response is not
greater than 2xx, the SPA will disconnect both PSTN and
VoIP call legs automatically. The range is 0-255.
The default is 30.
