Cisco Small Business ATA Administration Guide 136
B
Ring Back 2 Tone Your ATA device plays this ringback tone instead of
if the called party replies with a SIP 182
response without SDP to its outbound INVITE request. The
default value is the same as , except the
cadence is 1s on and 1s off.
The default is 440@-19,480@-19;*(1/1/1+2).
Confirm Tone Brief tone to notify the user that the last input value has
been accepted.
The default is 600@-16; 1(.25/.25/1).
SIT1 Tone Alternative to the Reorder Tone played when an error
occurs as a caller makes an outbound call. The RSC to
trigger this tone is configurable on the SIP screen.
The default is 985@-16,1428@-16,1777@-16;20(.380/0/
1,.380/0/2,.380/0/3,0/4/0).
SIT2 Tone Alternative to the Reorder Tone played when an error
occurs as a caller makes an outbound call. The RSC to
trigger this tone is configurable on the SIP screen.
The default is 914@-16,1371@-16,1777@-16;20(.274/0/
1,.274/0/2,.380/0/3,0/4/0).
SIT3 Tone Alternative to the Reorder Tone played when an error
occurs as a caller makes an outbound call. The RSC to
trigger this tone is configurable on the SIP screen.
The default is 914@-16,1371@-16,1777@-16;20(.380/0/
1,.380/0/2,.380/0/3,0/4/0).
SIT4 Tone Alternative to the Reorder Tone played when an error
occurs as a caller makes an outbound call. The RSC to
trigger this tone is configurable on the SIP screen.
The default is 985@-16,1371@-16,1777@-16;20(.380/0/
1,.274/0/2,.380/0/3,0/4/0).
MWI Dial Tone Played instead of the Dial Tone when there are unheard
messages in the callers mailbox.
The default is 350@-19,440@-19;2(.1/.1/1+2);10(*/0/
1+2).
Cfwd Dial Tone Played when all calls are forwarded.
The default is 350@-19,440@-19;2(.2/.2/1+2);10(*/0/
1+2).
