ATA Voice Field Reference
Line page
Cisco Small Business ATA Administration Guide 165
B
Ans Call Without
Reg
Expires value in sec in a REGISTER request. The PAP2T will
periodically renew registration shortly before the current
registration expired. This parameter is ignored if the
parameter is no. Range: 0 (231 1) sec
Use DNS SRV
Whether to use DNS SRV lookup for Proxy and Outbound
Proxy.
The default is no.
DNS SRV Auto
Prefix
If enabled, the PAP2T will automatically prepend the Proxy
or Outbound Proxy name with _sip._udp when performing
a DNS SRV lookup on that name.
The default is no.
Proxy Fallback Intvl
This parameter sets the delay (sec) after which the PAP2T
will retry from the highest priority proxy (or outbound
proxy) servers after it has failed over to a lower priority
server. This parameter is useful only if the primary and
backup proxy server list is provided to the PAP2T via DNS
SRV record lookup on the server name. (Using multiple
DNS A record per server name does not allow the notion of
priority and so all hosts will be considered at the same
priority and the PAP2T will not attempt to fall back after a
fail over).
The default is 3600
Proxy Redundancy
Method
PAP2T will make an internal list of proxies returned in DNS
SRV records. In normal mode, this list will contain proxies
ranked by weight and priority.
if Based on SRV port is configured the PAP2T does normal
first, and also inspect the port number based on 1st proxys
port on the list.
The default is Normal.
Voice Mail Server
Enter the URL or IP address of the server.
Mailbox Subscribe
Expires
Expiry time to the voice mail server. The time to send
another subscribe message to the voice mail server.
