Basic Administration and Configuration
Using the Administration Web Server
Cisco Small Business ATA Administration Guide 36
2
STEP 3 Complete the WAN configuration for DHCP, static IP addressing, or PPPoE.
For DHCP:
a. Select DHCP from the drop-down menu.
b. If you use a cable modem, you may need to configure the MAC Clone Settings.
(Contact your ISP for more information.)
c. If your service uses a specific PC MAC address, then select yes from the
setting.
d. Then enter the PCs MAC address in the field.
For Static IP Addressing:
a. Select Static IP from the drop-down menu.
b. In the Static IP Settings section, enter the IP address in the field, the
subnet mask in the field, and the default gateway IP address in the
field.
c. In the Optional Settings section, enter the DNS server address(es) in the
and optional fields.
For PPPoE:
a. Select PPPoE from the drop-down menu. This is the correct
setting for most DSL users.
b. Enter the values provided by the ITSP in the following fields:
 PPPoE Login Name
 PPPoE Login Password
 PPPoE Service Name
STEP 4 Click . The ATA device reboots.
STEP 5 To verify your progress, click the tab and then click . Under
, confirm the , , ,
, and .
