Cisco SPA2102 User Manual

Configuring Dial Plans
Cisco Small Business ATA Administration Guide 57
4
Digit Sequence Function
Enter any of these characters to represent a key
that the user must press on the phone keypad.
Enter to represent any character on the phone
keypad.
Enter characters within square brackets to create
a list of accepted key presses. The user can press
any one of the keys in the list.
 Numeric range
For example, you would enter to allow the
user to press any one digit from 2 through 9.
 Numeric range with other characters
For example, you would enter
to allow
the user to press 3, 5, 6, 7, 8, or *.
(period)
Enter a period for element repetition. The dial plan
accepts 0 or more entries of the digit. For
example, allows users to enter 0, 01, 011,
0111, and so on.
For sequence substitution, use this format to
indicate that certain dialed digits are replaced by
other characters when the sequence is
transmitted. The digits can be zero or
more characters.
EXAMPLE 1:
When the user presses 8 followed by a seven-
digit number, the system automatically replaces
the dialed 8 with 1650. If the user dials
85550112, the system transmits 16505550112.
EXAMPLE 2:
In this example, no digits are replaced. When the
user enters a 10-digit string of numbers, the
number 1 is added at the beginning of the
sequence. If the user dials 9725550112, the
system transmits 19725550112
