Device Status
Cisco SA500 Series Security Appliances Administration Guide 206
10
LAN Interface
IP Address LAN IP address of the router,.
DHCP Mode: Displays the router’s DHCP server mode. The
mode can be Disabled, Server, or Relay.
WAN Interface
IP Address IP address for the primary (dedicated) WAN port.
State Indicates if the WAN connection is UP or DOWN.
State will be UP if the link is up and the WAN
interface has an IP.
Optional Port (WAN/DMZ/LAN)
IP address IP address of the Optional Port. When the Optional
Port is in LAN mode, this field will not be displayed.
State Indicates if the connection is UP or DOWN. When
the Optional Port is in LAN or DMZ mode, this field
is not displayed. In WAN mode, the state will be UP
if the link is up and the WAN interface has an IP.
Access Points (only applies to SA 520W)
Shows how many access points are configured on
the SA 520W and how many users are associated
with each SSID.
Site to Site VPN
All Tunnels Number of active Site-to-Site VPN tunnels and the
total number of configured Site-to-Site VPN
tunnels.
Remote Access VPN
SSL Users Number of active SSL users.
IPsec Users Number of IPsec users.
