Configuring VPN
Configuring SSL VPN for Browser-Based Remote Access
Cisco SA500 Series Security Appliances Administration Guide 163
7
Specifying the Network Resources for SSL VPN
Network resources are services or groups of LAN IP addresses that are used to
easily create and configure SSL VPN policies. This shortcut saves time when
creating similar policies for multiple remote SSL VPN users.
STEP 1 Click VPN > SSL VPN Server > Resources.
The Resources window opens.
STEP 2 To add a network resource, click Add.
Other options: Click the Edit button to edit an entry. To delete an entry, check the
box and then click Delete. To select all entries, check the box in the first column of
the table heading.
STEP 3 Enter the following information:
• Resource Name: Enter a unique name to identify this resource.
• Service: Choose one of the supported SSL VPN services to associate with
this resource.
STEP 4 Click Apply to save your settings.
Configuring SSL VPN Port Forwarding
Port Forwarding is used when you want to allow access only to a limited set of
resources. For example, you may want the SSL VPN users to access the email
service only. Port forwarding is different from split and full tunnel modes, which
allow access to all ports for a give subnet.
The following table lists some common applications and corresponding TCP port
numbers:
TCP Application Port Number
FTP Data (usually not needed) 20
FTP Control Protocol 21
SMTP (send mail) 25
