Networking
Configuring the Optional WAN
Cisco SA500 Series Security Appliances Administration Guide 54
2
Configuring the Optional WAN
You can configure the Optional port for use as an optional WAN, allowing you to
set up two ISP links for your network. You can use one link as the primary link and
one for backup purposes, or you can configure load balancing to use both links at
the same time.
STEP 1 First configure the Optional port for use as a WAN port:
a. Click Networking > Optional Port > Optional Port Mode,
or from the Getting Started (Advanced) page, under Secondary WAN Port,
click Set Optional Port to WAN.
The Optional Port Mode window opens.
b. Choose WAN.
c. Click Apply to save your settings.
If you are using the Getting Started (Advanced) page, click Getting Started >
Advanced to return to the list of configuration tasks.
STEP 2 Click Networking > Optional Port > WAN, or from the Getting Started (Advanced)
page, under Secondary WAN Port, click Configure WAN settings for Optional
Port.
STEP 3 The WAN Configuration window opens.In the ISP Configuration area, check the
Internet Connection Require a Login box if your ISP requires a login every time
you connect to the Internet.
• If you checked the box, complete the fields in the ISP Connection Type area.
• If you did not check the box, continue complete the fields in the Internet (IP)
Address area and Dynamic Name System (DNS) Servers area.
STEP 4 If your Internet connection requires a login, enter the settings in ISP Connection
Type area:
• ISP Connection Type: Choose the connection type, as specified by your
service provider: PPTP, PPPoE, or L2TP. Then complete all fields that are
highlighted with white backgrounds.
• PPPoE Profile Name: Choose a PPPoE profile. To manage the profiles in the
drop-down list, see Creating PPPoE Profiles, page 40.
• User Name: The user name that is required to log in
