Networking
Configuring the Optional WAN
Cisco SA500 Series Security Appliances Administration Guide 60
2
NOTE Next steps:
• If you are using the Getting Started (Advanced) page, click Getting Started
> Advanced to continue with the list of configuration tasks.
• Required for load balancing: If you chose the Load Balancing option, click
Optional Port > Protocol Bindings to configure your protocol bindings. For
more information, see Configuring the Protocol Bindings for Load
Balancing, page 60.
Configuring the Protocol Bindings for Load Balancing
If you chose Load Balancing as the Port Mode for your Optional WAN, you
configure protocol bindings to determine how the traffic is balanced between the
two ISP links. This feature can be used to segregate traffic between links that are
not of the same speed. High volume traffic can be routed through the port
connected to a high speed link and low volume traffic can be routed through the
port connected to the slow link.
For example, you can bind the HTTP protocol to the Dedicated WAN and bind the
FTP protocol to the Optional WAN. In this scenario, the security appliance
automatically channels FTP data through the Optional WAN. All HTTP traffic is
routed through the Dedicated WAN.
NOTE Before you can enter the protocol bindings, you must configure the optional port,
the WAN connection, and the WAN port mode. For more information, see
Configuring Auto-Rollover, Load Balancing, and Failure Detection, page 57.
If you want to enter a protocol binding for a custom service, you must first add the
custom service to the database. See Creating Custom Services, page 104.
STEP 1 Click Networking > Optional Port > Protocol Bindings, or from the Getting
Started (Advanced) page, under Secondary WAN Port, click Configure Protocol
Bindings (Optional - if WAN Mode set to Load Balancing).
The Protocol Bindings window opens. Any existing protocol bindings appear in the
List of Available Protocol Bindings table.
STEP 2 Click Add.
