Networking
QoS Bandwidth Profiles
Cisco SA500 Series Security Appliances Administration Guide 72
2
QoS Bandwidth Profiles
You can configure Quality of Service (QoS) Bandwidth Profiles for the WAN and
the LAN.
For traffic from the secure zone to the insecure zone, QoS is determined by
limiting the speed as well assigning a priority. To do so, create bandwidth profiles
and assign traffic classes to them. The traffic selector identifies the stream of
traffic that is subject to the specified bandwidth management profile.
NOTE Bandwidth limiting is not applicable to a DMZ interface.
Creating QoS Bandwidth Profiles for WAN Interfaces
STEP 1 Click Networking > QoS > WAN QoS.
The Bandwidth Management window opens. Any existing profiles appear in the
Bandwidth Profiles table.
STEP 2 To enable this feature check the box at the top of the page and click Apply.
STEP 3 In the WAN Configuration area, specify the Upstream Bandwidth in Kbps and
the Downstream Bandwidth in Kbps for each WAN interface by entering the
values provided by your ISP. Then click Apply.
STEP 4 In the Bandwidth Profiles Enable area, do the following:
• Check the box to enable the bandwidth profiles.
• Click Apply to save your settings.
STEP 5 Click Add to add a new bandwidth profile.
Other options: Click the Edit button to edit an entry. To delete an entry, check the
box and then click Delete. To select all entries in the table, check the box at the left
side of the heading row.
