Page #70 background imageLoading...
Page #70 background image
Networking
Port Management
Cisco SA500 Series Security Appliances Administration Guide 70
2
- RIP-2B broadcasts data in the entire subnet.
- RIP-2M sends data to multicast addresses.
STEP 3 In the Authentication for RIP 2B/2M area, enter the following information:
Enabled Authentication for RIP 2B/2M: Check this box to enable
authentication for RIP-2B or RIP-2M.
First Key Parameters and Second Key Parameters
- MD5 Key ID: Input the unique MD-5 key ID.
- MD5 Auth Key: Input the auth key for this MD5 key.
- Not Valid Before: Start date of the First Key for MD5 based
authentication between routers.
- Not Valid After: End date of the First Key for MD5 based authentication
between routers.
STEP 4 Click Apply to save your settings.
Port Management
You can enable or disable ports, set the duplex mode and speed, and enable or
disable port mirroring. Refer to the following topics.
Configuring the Ports, page 70
Configuring SPAN (Port Mirroring), page 71
Configuring the Ports
STEP 1 Click Networking > Port Management > Port Management.
The Port Management window opens.
STEP 2 Choose the following options for each port:
Enable: Check this box to enable the port. To disable the port, uncheck the
box. By default all ports are enabled.
