Note: For more information about E1 and T1 cable pinouts and cable
connections, see:
• 4.9 E1/T1 Matrix to Matrix straight cable connections in this
document.
• 4.10 E1 to FreeSpeak / CellCom / FreeSpeak II antenna straight
cable connection in this document.
8.3.1 FreeSpeak/CellCom/ FreeSpeak II application
The E-QUE interface cards can be configured for FreeSpeak/CellCom/
FreeSpeak II use in two modes, depending on whether antennas or splitters
are to be connected.
If the E-QUE interface card is configured:
• In Antenna mode all eight E1/T1 ports can be used to connect up to
eight antennas.
• To support splitters, only two ports are active (ports 1 and 5)
allowing a maximum of two splitters to be connected. Each splitter can
support up to five antennas.
When the E-QUE interface cards are used in FreeSpeak/CellCom/ FreeSpeak II
mode, they cannot be connected to the antennas via third party equipment or
via fiber as the antennas require the DECT sync signal and this will not be
converted by third party equipment or fiber interfaces.
Three connections schemes are illustrated below.
