User Guide | Eclipse HX-Delta
Page 99
8.2 E-QUE rear panel connectors
Figure 8-2: E-QUE rear panel connectors
LAN
A
B
Ref in
DECT
Ref out
E-QUE
1 – 4
5 – 8
C
D
