Analog port card outputs
Level
0 dBu nominal/18 dBu max.
Impedance
100 Ohms balanced
Frequency Response
30 Hz–22 kHz ± 3 dB
Distortion
<0.05 %, @ 0 dBu, 300 Hz to 10 kHz;
<0.1 %, @ 0 dBu, 100 Hz to 20 kHz
Analog port card inputs
Level
0 dBv nominal /18 dBu max.
Impedance: card Mark 1
600 Ohms balanced
Impedance: card Mark 2
>10K Ohms balanced
Frequency Response
30 Hz–22 kHz ± 3 dB
Distortion
<0.05 %, @ 0 dBu, 300 Hz to 10 kHz;
<0.1 %, @ 0 dBu, 100 Hz to 20 kHz
Table 15-25: Analog port card (MVX-A16) (Note difference in output impedence
between card 1. and card 2.)
15.27 Data interface: 16 bi-directional
Category
Measures / comments
Input Format
RS-422 @ 2400 to 19200 kb/s
Output Format
RS-422 @ 2400 to 19200 kb/s
Input Termination
100 ohm ± 10%
Output Termination
None; expected at User Panel
Isolation
None; expected at User Panel
Table 15-26: Data interface: 16 bi-directional
15.28 Backplane connector: FCI/BERG Metral
Category
Measures / comments
Port Connector
RJ-45 to Clear-Com standard pinout
Transmission Distance
3000 ft. (1000 m) maximum
Table 15-27: Data interface: 16 bi-directional

Clear-Com eclipse HX-Delta Specifications

General

Brand	Clear-Com
Model	eclipse HX-Delta
Category	Intercom System
Language	English
