User Guide | Eclipse HX-Delta
Key: Eclipse HX-Delta rear panel
DC power supply connectors. For more information about the
12V external power supplies, see 3.3.4 Power supplies.
Spare slots for interface card rear connector panels. All front
installed interface cards require a corresponding rear connector
panel. Blank panels can be installed to unused slots.
The Eclipse HX-Delta has 4 slots available for interface cards. For
more information, see 3.4 Interface cards.
CPU card rear panel. The CPU card rear panel houses connectors
for an external PC, network, interfaces, alarms and other matrices.
Up to 2 CPU cards can be installed to the matrix, but only one rear-
panel CPU card is required. Whichever of the two front-installed
CPU cards is acting as master will work in conjunction with this
card. For more information, see 3.3.6 CPU card.
LAN / PNL connector. Rear to front Ethernet / panel feed through
Interface module slots. The Eclipse HX-Delta has 3 built-in
interface module slots. For more information, see 3.5.Interface
modules
Table 3-3: Key: Eclipse HX-Delta rear panel
3.3.4 Power supplies
The Eclipse HX-Delta matrix has two external 12V power supplies for redundant
operation. One power supply unit can power an entire matrix. The second unit
provides a backup in case of failure or damage to the first unit.
The two external supplies have separate IEC connectors to AC mains, and are
designed for completely automatic and transparent changeover between supplies
in the event of a power outage in one of the AC mains circuits.
Each power supply has an input voltage between 100-240 VAC, 50-60Hz.
3.3.5 Main features of the Eclipse HX-Delta
Features of the Eclipse HX-Delta matrix system include:
3RU metal frame, with handles to expedite
placement in the rack.
Full audio bandwidth throughout the signal
chain, producing superior broadcast audio
quality. The system maintains 24-bit depth, a
