Panel
Description
CPU card
A CPU-card rear panel holds the
various connectors associated with the
CPU card, such as the RS-232
connector for the configuration
computer.
Analog port card (MVX-A16)
Analog port-card rear panel holds the
sixteen RJ-45 connectors associated
with its corresponding analog port-
card front panel.
User panels and interface modules
connect to the matrix through this
rear-connector panel.
E-MADI64 card
An E-MADI64 rear card comprises a
MADI fiber connector, MADI input and
output coaxial cable connectors, and a
coaxial Video / Word clock input.
E-FIB fiber card
An E-FIB fiber card provides two ports
to connect fiber network cables.
E-QUE card
An E-QUE card provides eight RJ-45
ports for connection to wireless
equipment and three RJ-45 ports for
DECT sync and LAN connections.
IVC-32 card
An IVC-32 card provides a RJ-45 port
for connection to an IP network. No
other ports are used.
LMC-64 card
An LMC-64 card provides a RJ-45 port
for connection to an IP network. No
other ports are used.
Table 5-3: Rear connector panels
Note: A blank panel covers an unused slot in the matrix.
5.8.2 Connecting the CPU Card
The rear-connector panel associated with the CPU card holds seven connectors
Note: For a detailed description of each connector, including wiring and
pinout information, see 4.7.1 CPU card interface connectors.
A matrix only requires one rear-panel CPU card, because whichever of the two
front-installed CPU cards is acting as master will work in conjunction with this
card. All other front cards, however, require their own rear-connector panel.
Note: For detailed information about connecting the matrix to panels, interfaces and
other devices, see 4 Installing the Eclipse HX-Delta.
