4.8 DSE1/T1 Matrix to Matrix crossover cable
connections
For E1 and T1 direct matrix to matrix connections the CAT5 crossover cables
should be wired, as shown in the table below:
Matrix 1 Pin
Description
Matrix 2 Pin
1
To
4
2
To
5
3
Not connected
3
4
To
1
5
To
2
6
Not connected
6
7
Not connected
7
8
Not connected
8
Table 4-4: E1/T1 Crossover cable
4.9 E1/T1 Matrix to Matrix straight cable connections
E1/T1 straight cables may be used to connect E1 or T1 ports to E1 or T1
networks or third party equipment, as shown in the table below:
Matrix 1 Pin
Description
Matrix 2 Pin
1
To
1
2
To
2
3
Not connected
3
4
To
4
5
To
5
6
Not connected
6
7
Not connected
7
8
Not connected
8
Table 4-5: E1/T1 Straight cable
4.10 E1 to FreeSpeak / CellCom / FreeSpeak II
antenna straight cable connection
Straight CAT5 cables are used to connect an E-QUE card to a FreeSpeak /
CellCom / FreeSpeak II antenna or splitter.
