The E1 pinout for connecting an antenna or splitter is shown in Table 4-6 E1
pinout for connecting a FreeSpeak / CellCom / FreeSpeak II antenna or
splitter.
Cable wiring is shown in Table 4-7: E1 to FreeSpeak / CellCom / FreeSpeak
II antenna or splitter straight cable connection.
Pin
Description
1
Tx+
2
Tx-
3*
DECTSYNC+
4
Rx+
5
Rx-
6*
DECTSYNC-
7*
GND
8*
12V
Table 4-6 E1 pinout for connecting a FreeSpeak / CellCom / FreeSpeak II antenna or
splitter
Matrix 1 Pin
Description
Matrix 2 Pin
1
To
1
2
To
2
3
Not connected
3
4
To
4
5
To
5
6
Not connected
6
7
Not connected
7
8
Not connected
8
Table 4-7: E1 to FreeSpeak / CellCom / FreeSpeak II antenna or splitter straight cable
connection
