9 IVC-32 card for IP-based connections
The IVC-32 (Instant Voice Communication) interface card provides the
Eclipse HX-Delta with connectivity over IP to V-Series IP panels and
Concert servers.
Each IVC-32 interface card comprises:
• A front card with a reset button and various status indicators (including
status LEDs for power, port activity and LAN status).
Note: The port activity LEDs are not active on the IVC-32 front card
as the E1/T1 ports are not used.
• A rear card with eleven RJ-45 ports giving eight E1/T1 ports (not used),
DECT sync in and out (not used) and a LAN port used for the IP
connection.
Note: An Ethernet cable must be connected to the IVC-32 interface
LAN port for the card to function correctly.
For an overview of the Eclipse HX-Delta, see 3 Overview in this document.
