User Guide | Eclipse HX-Delta
Page 117
10 LMC-64 metering card
The Level Meter Card (LMC-64) interface card enables the Eclipse HX-Delta to provide
audio level metering for Production Maestro Pro over a network.
Each LMC-64 interface card can meter up to 64 virtual partylines (conferences) and
four-wire ports.
The LMC-64 interface comprises:
• A front card with a reset button and various status indicators (including status LEDs
for power, port activity and LAN status).
Note: The port activity LEDs are inactive on the LMC-64 front card as
the E1/T1 ports are not used.
• A rear card with eleven RJ45 ports giving eight E1/T1 ports (not used), DECT sync
in and out (not used) and a LAN port used for the IP connection.
Note: An Ethernet cable must be connected to the LMC-64 interface LAN port for the
card to function correctly.
For an overview of the Eclipse HX-Delta, see 3 Overview in this document.
