User Guide | Eclipse HX-Delta
Page 21
sampling rate of 48kHz, and 30 Hz to 22 kHz
frequency response.
Interface cards
Support for 4 interface cards, including MVX-
A16, E-FIB, E-MADI64, IVC-32, LMC-64, E-QUE
cards.
For more information, see 3.4 Interface cards.
Interface modules
Support for 3 interface modules (used to
connect the matrix to telephones, two-way
radios, camera intercoms, partylines, and other
intercom devices).
For more information, see 3.5.Interface
modules.
Redundancy
Fail-safe redundancy is achieved with two CPU cards
and two external power supplies.
Note: Power supplies automatically switch to the
correct voltage, for compatibility around the
world.
GPIs / GPOs
Eight general purpose inputs and eight relays,
located directly on the matrix.
User panels
Full compatibility with V-Series and i-Series user
panels.
VOX
The VOX-programmable audio visually cues you
at the matrix when audio transmits at a
programmed threshold on a connected user
panel or interface.
EHX configuration
software
EHX provides an intuitive and visual way to
configure the Eclipse HX matrix system. The
Eclipse HX-Delta can store up to four system
configurations.
Table 3-4: Eclipse HX-Delta features
Note: The number of interface cards that can be fitted to the matrix is limited by port
count. For more information, see 4.4.3 Combining interface cards in the
matrix in this document.
3.3.6 CPU card
Two CPU cards are fitted to each Eclipse HX-Delta, in a master and slave
relationship. The second CPU card provides redundancy in the case of outages or
planned maintenance.
The master CPU card:
