7.2 E-FIB rear panel lights and connectors
Figure 7-2: E-FIB rear panel lights and connectors
Warning: Eye Safety
This laser based single mode transceiver is a Class 1 Laser product. It
complies with IEC 60825-1/A2:2001 and FDA performance standards for laser
TXVRB
C
A
+3.3V
TXVRA
RX
TX
RX
TX
B
RX
TX
Transceiver lasers
