15 Specifications
0 dBu is referenced to 0.775 volts RMS.
15.1 Matrix capabilities
Category
Number / Comments
Maximum Interface Cards
4
Ports per MVX-A16 Card
16
Maximum MVX-A16 Cards
4
Maximum CPU Cards
2 (included)
Maximum Fiber Interface
Cards
2
Maximum E-Que or IVC-32 or
LMC-64 Expansion Cards
4 (in total)
Maximum External Power
Supplies
2 (included)
Maximum RJ-45 Ports per
Matrix
64
Maximum Timeslots
512 (some used for internal purposes)
Table 15-1: Matrix capabilities
15.2 Mechanical
Category
Measures / comments
Height
3 RU (5.25 inches or 133.35 mm)
Width
19 inches (482 mm)
Depth
16.57 inches (420 mm)
Weight
8 to 15 kg
Table 15-2: Mechanical
15.3 Environmental
Category
Measures / comments
Operating Temperature
0º C to +40º C, ambient
