Key to Figure 41: IVC-32 front panel lights and controls
RESET button
Pressing the reset button causes the card and all links to
momentarily stop their current activity and to restart.
During the reset, configuration information downloads to the
card from the CPU card. If the entire system is operating except
for one IVC-32 interface card, press the reset button for that
card only.
Tip: The reset button is slightly recessed from the front panel to
prevent it from being accidentally pressed. A tool such as a bent
paper clip is required to press this button.
Power supply light
+3.3-Volt Power Supply Light
The matrix’s +3.3-volt power supply provides electric current to
this green light. When lit, the light indicates that the +3.3-volt
supply is present and supplying power to the card.
Status lights
When lit, a yellow status light indicates IP communication
between the card and E1/T1 connected devices. The first status
light represents the first four connected panels, the second the
next four panels, and so on.
Under normal circumstances, however, E1/T1 devices are not
connected to an IVC-32 interface card, which means that these
lights are normally inactive.
LAN DATA light
The green LAN DATA light illuminates to indicate there is data
passing through the Ethernet port.
LAN LINK light
The amber LAN LINK light illuminates to indicate a connection
to the LAN port.
Table 9-1: Key to IVC-32 front panel lights and controls
