Clear-Com eclipse HX-Delta User Manual

User Guide | Eclipse HX-Delta
Page 127
100Mbps will only support a small number of Dante channels. A
Fiber connection is always 1Gbps and is always green.
F
Active LED
The Active (matrix data) LED flashes green (1:1 at 1Hz) to
indicate successful communication between the E-DANTE64-HX
interface and the CPU card. This LED will flash twice as fast
while a card is being upgraded and firmware is being installed
(EHX firmware only, the light will stay as normal while Dante
firmware is being installed).
Error LED
Possible error conditions:
1. Expected networks not connected on back of card (See
EHX Configuration User Guide for redundancy options
for this card).
2. Card configuration does not match card or cards
installed. The name on a card in a card slot does not
match the name the EHX software has for that slot.
During boot up, the Active and Error LEDS flash rapidly until
the boot sequence is completed.
