RJ45 LAN ports 1 – 4.
These can be used for: Clear-Com panels, directs, trunks, LQ, Agent-IC.
They can also be used for FSII IP Transceivers. One of the ports can be
designated as an ADMIN port and used for maintenance. The
functionality of these ports is configured in the EHX software.
Although there are 6 LAN ports on this card, only 3 IP addresses can be
configured.
RJ45 DECT sync ports.
These connectors can be used when you are using two separate DECT
systems in the same area. Connecting the systems with the DECT sync
connector ensures that all connected clocks are synchronized together.
This avoids clashes when many DECT devices are in use in the same RF
space.
DECT sync can be established between matrices, bases and third party
systems.
See DECT Sync Pinouts in the FreeSpeak II User Guides.
USB C
USB maintenance port.
LAN ports 5 and 6. Fiber, AES67 only.
As with ports 1 – 4, the functionality of these ports is configured in the
EHX software. They are designed to be used in AES67 networks for FSII
IP transceivers.
Although there are 6 LAN ports on this card, only 3 IP addresses are
available.
Use this slot to install an SFP/Mini-GBIC.
E1 Fiber ports (for future use)
Note: The E-IPA card has four Media Access Control (MAC) addresses. These are
printed on the card.
