When an older, unsupported version of the MVX or E-QUE FPGA is
detected, the EQUE FPGA VERSION USUPPORTED message is
displayed by the master CPU card.
Note:
The dot matrix lights will also display system information when
the ENG button is pressed on the master CPU card. This is
described below in the section on the ENG button.
Status lights
OK Light
When flashing green, the OK light indicates that the CPU card is
successfully communicating with the EHX configuration software.
IPC (Interprocessor Communication) Light
The Interprocessor Communication (IPC) light only operates when
there are two CPU cards in the matrix. When lit green, the light
indicates that the two CPU cards are exchanging information.
Master Light
An Eclipse HX-Delta system can have two CPU cards, although the
system will operate with only one. If the primary card becomes
unavailable for any reason, the second card can serve as backup
while the primary card is repaired or replaced.
The master light is lit green on whichever CPU card is currently
serving as master. If there is a backup CPU card in the matrix, its
“master” light will not illuminate if the primary card is acting as
master.
LAN A Light
When a local area network (LAN) is connected to the matrix’s LAN
A port, the CPU card’s LAN A LED is lit green to indicate a
connection to the Eclipse Configuration Software LAN A port.
LAN B Light
When a second local area network is connected to the matrix’s
“LAN B” port, the CPU card’s LAN B LED is lit green to indicate a
connection to the Eclipse Configuration Software (EHX) LAN B
port.
Sync Light
When multiple Eclipse HX matrices are connected together the
Sync light is lit green to indicate that the matrices are connected
and synchronized.
SI Light
The SI light flashes green to indicate communications activity.
