InteliDrive DCU Industrial 3.4.0 Global Guide
242
Related FW 3.4.0 Related applications AS, SS
Comm object 57
Description
If there is an additional terminal board between a thermocouple sensor and the IS-AIN8 (TC) module and
there is a significant temperature difference between this terminal board and the module, it is necessary to
measure the temperature at this terminal board and use this temperature for the thermocouple compensation
instead of the internal temperature of the module.
Cold Temp 1 Logical Analog input is intended for measurement of this thermocouple compensation
temperature for the IS-AIN8 (TC) module with index #1, Cold Temp 2 corresponds to IS-AIN8 (TC) module
with index #2 etc.
Note: Thermocouples without internal compensation "Thermo(nc)..." must be used for this case.
Cold Temp 2
6 back to List of LAI
Related FW 3.4.0 Related applications AS, SS
Comm object 58
Description
If there is an additional terminal board between a thermocouple sensor and the IS-AIN8 (TC) module and
there is a significant temperature difference between this terminal board and the module, it is necessary to
measure the temperature at this terminal board and use this temperature for the thermocouple compensation
instead of the internal temperature of the module.
Cold Temp 1 Logical Analog input is intended for measurement of this thermocouple compensation
temperature for the IS-AIN8 (TC) module with index #1, Cold Temp 2 corresponds to IS-AIN8 (TC) module
with index #2 etc.
Note: Thermocouples without internal compensation "Thermo(nc)..." must be used for this case.
Cold Temp 3
6 back to List of LAI
Related FW 3.4.0 Related applications AS, SS
Comm object 59
Description
If there is an additional terminal board between a thermocouple sensor and the IS-AIN8 (TC) module and
there is a significant temperature difference between this terminal board and the module, it is necessary to
measure the temperature at this terminal board and use this temperature for the thermocouple compensation
instead of the internal temperature of the module.
Cold Temp 1 Logical Analog input is intended for measurement of this thermocouple compensation
temperature for the IS-AIN8 (TC) module with index #1, Cold Temp 2 corresponds to IS-AIN8 (TC) module
with index #2 etc.
Note: Thermocouples without internal compensation "Thermo(nc)..." must be used for this case.
Cold Temp 4
6 back to List of LAI
