9 Troubleshooting 119
9
3.14 ERROR 24 K(Ve) Value Out of Range
Timing:
The last DET in K(Ve) Automatic Setup
Criteria:
Calculated K(Ve) exceeded 100L.
Probable Cause
Treatment
The current K(Ve) settings does not match the
calibrator used for K(Ve) Automatic Setup causing
the measured value exceeding 100L.
Check the settings for the calibrator.
Go to: K(Ve) > K(Ve)Settings > Basic
The items are to be set varies depending on the calibrator used for K(Ve)
Automatic Setup.
ALC: ALC Displacement or ALC Reading
Leak Master: LM Flow [mL/min]
Output Signal Timing Chart
PIN#
Function TYPE WAIT DL1 PCHK PCHG PEXH CHG BAL1 DL2 BAL2 DET BLW EXH END WAIT
Standard
D-SUB
1B
18
STAGE #0
NO
2B
17
STAGE #1
NO
3B
16
ERROR
NO
5B
14
PASS
NO
6B
13
UL FAIL
NO
9B
36
BUSY
NO
10B
35
END
NO
12B
33
LL2 FAIL
NO
13B
32
LL FAIL
NO
14B
31
UL2 FAIL
NO
3.15 ERROR 25 Leak Limit Out of Range
Timing:
The last DET in K(Ve) Automatic Setup
Criteria:
K (Ve) Leak limits exceeded the DPS range after K(Ve) Automatic Setup
Probable Cause
Treatment
Leak limits exceeded the DPS range
after executing the K(Ve) Automatic
Setup.
Change the Leak unit to a pressure unit and perform K(Ve) Automatic Setup again.
Go to: Settings > Advanced Settings> Unit > Leak
Output Signal Timing Chart
PIN#
Function TYPE WAIT DL1 PCHK PCHG PEXH CHG BAL1 DL2 BAL2 DET BLW EXH END WAIT
Standard
D-SUB
1B
18
STAGE #0
NO
2B
17
STAGE #1
NO
3B
16
ERROR
NO
5B
14
PASS
NO
6B
13
UL FAIL
NO
9B
36
BUSY
NO
10B
35
END
NO
12B
33
LL2 FAIL
NO
13B
32
LL FAIL
NO
14B
31
UL2 FAIL
NO
At the end of
last DET in K(Ve) Automatic Setup▼
At the end of
last DET in K(Ve) Automatic Setup▼
